Haitech: the leader of DTMB standard output of digital TV
One screen captures a thousand scenes, a world of difference begins—every moment feels like being there.
PANEL | |
Size | 55" /65" /75" |
Active Display Area | 1209.6(H) x 680.4 ((V) 1428.48(H) x 803.52 ((V) 1650.24(H) x 928.26 (V) |
Pixel Pitch | 0.105 (H) x 0.315 (V) 0.124 (H) x 0.372 (V) 0.14325 (H) x 0.42975 ( (V) |
Max. Resolution | 3840×2160 |
Aspect Ratio | 16:9 |
Brightness(MAX) | 220cd/m2坎德拉/ 240cd/m2坎德拉 |
Response Time (Gray to Gray) | 8.5ms |
Back Light | LED |
Lamp Life(MIN) | 30,000 HS |
OD | 22/35 |
MONITOR DISPLAY SYSTEM | |
16 : 9 | YES |
4 : 3 | YES |
SMART SYSTEM SPEC | |
OS | Google 3.0 |
CPU | CA75*2@1.3Ghz+A55*2@1.15Ghz |
CPU Frequency | 1.3GHz |
GPU | BXE4-32MC1 |
GPU Frequency | 700Mhz |
DDR SIZE | 2G |
FLASH | 16G |
AUDIO | |
Speaker | 2X10W(8Ω) |
OUTPUT TERMINAL | |
RJ45 | X1 |
OPTICAL | X1 |
HDMI Input | X4 |
AV | X1 |
EARPHONE Out | X1 |
RF | X2 |
USB | X3 |
POWER | |
Power Input | 100-240V~ 50/60HZ |
Power Consumption | 138W/180W |
Power Saving | <0.5W |
ACCESSORY | |
Power Cord | NO |
Remote Control | YES |
Instruction Manual (in English) | YES |
HOUSING COLOR | |
Front bazel | black |
Stand | black |
Back Cover | black |
PANEL | |
Size | 55" /65" /75" |
Active Display Area | 1209.6(H) x 680.4 ((V) 1428.48(H) x 803.52 ((V) 1650.24(H) x 928.26 (V) |
Pixel Pitch | 0.105 (H) x 0.315 (V) 0.124 (H) x 0.372 (V) 0.14325 (H) x 0.42975 ( (V) |
Max. Resolution | 3840×2160 |
Aspect Ratio | 16:9 |
Brightness(MAX) | 220cd/m2坎德拉/ 240cd/m2坎德拉 |
Response Time (Gray to Gray) | 8.5ms |
Back Light | LED |
Lamp Life(MIN) | 30,000 HS |
OD | 22/35 |
MONITOR DISPLAY SYSTEM | |
16 : 9 | YES |
4 : 3 | YES |
SMART SYSTEM SPEC | |
OS | Google 3.0 |
CPU | CA75*2@1.3Ghz+A55*2@1.15Ghz |
CPU Frequency | 1.3GHz |
GPU | BXE4-32MC1 |
GPU Frequency | 700Mhz |
DDR SIZE | 2G |
FLASH | 16G |
AUDIO SYSTEM | |
Speakers | 2X10W(8Ω) |
OUTPUT TERMINALS | |
| RJ45 | X1 |
OPTICAL | X1 |
HDMI Input | X4 |
AV | X1 |
EARPHONE Out | X1 |
RF | X2 |
USB | X3 |
POWER SUPPLY | |
Power Input | 100-240V~ 50/60HZ |
Power Consumption | 138W/180W |
Power Saving | <0.5W |
ACCESSORIES | |
Power Cord | NO |
Remote | YES |
User Manual (English) | YES |
HOUSING COLOR | |
Front bazel | black |
Stand | black |
Back Cover | black |
